تحليل صور مجهر القوة الذرية بالبايثون ( تحديث جديد)
AFM image analysis with Python


تحليل صور مجهر القوة الذرية بالبايثون
AFM Surface Analyzer · v2.1أداة تقرأ صورة الارتفاعات من مجهر القوة الذرية بوحداتها الحقيقية، وتحسب معاملات الخشونة المساحية حسب ISO 25178، وتحلل طيف السطح وحبيباته، ثم تصدر تقريرًا كاملًا بصيغة PDF.
البرنامج لويندوز 10 أو 11 بنظام 64 بت، وحجمه نحو 80 ميغابايت. قد تظهر نافذة SmartScreen عند أول تشغيل لأن البرنامج غير موقّع رقميًا؛ اختر «مزيد من المعلومات» ثم «تشغيل على أي حال». أما نسخة Colab فتحتاج حساب Google فقط.
تقبل الأداة ملفات Gwyddion وBruker/NanoScope وSDF ومصفوفات الارتفاع النصية وملفات XYZ، ويمكن رفع عدة عينات معًا لمقارنتها.
ماذا تعطيك الأداة
- معاملات الارتفاعSa وSq وSsk وSku وSp وSv وSz وS10z: حجم انحرافات الارتفاع وتوزيعها وقيمها القصوى.
- المعاملات المكانيةSal الحجم الجانبي النموذجي للمعالم، وStr تماثل السطح في الاتجاهات، وStd اتجاه الخطوط إن وُجدت.
- المعاملات الهجينةSdq متوسط ميل السطح، وSdr الزيادة في المساحة الحقيقية على المساحة المسقطة.
- الطيف والبعد الكسريكثافة القدرة الطيفية PSD، ومنها أس هيرست H والبعد الكسري Df مع جودة الملاءمة.
- دالة الارتباطدالة ارتباط الارتفاع G(r)، ومنها أس الخشونة α وطول الارتباط الجانبي ξ.
- الحبيباتالعدد والكثافة لكل ميكرومتر مربع، والقطر المكافئ وتوزيعه، ونسبة التغطية، مع فصل الحبيبات المتلاصقة.
- تقرير PDFتقرير بهوية المعامل، بالعربية أو بالإنجليزية: الخريطة والمنظر ثلاثي الأبعاد، وجدول المعاملات، والرسوم، وكل خطوة معالجة طُبقت، والتنبيهات.
- ملفات للتحريرجداول المعاملات والحبيبات بصيغة CSV، والرسم بصيغة PNG بدقة 300 نقطة في البوصة.
طريقة الاستخدام
جهّز الدفتر
شغّل الخلية الأولى مرة واحدة، فهي تحمّل خط المعامل وشعاره للتقرير.
ارفع الملفات
شغّل خلية الأداة واختر ملفًا أو أكثر. تظهر تحت كل ملف أبعاده وطول المسح ووحدة الارتفاع كما قرأتها الأداة، فراجعها قبل أن تكمل.
أكمل الوحدات الناقصة
إن كان الملف النصي بلا أبعاد فاكتب طول المسح بالميكرومتر، وإن كان بلا وحدة للارتفاع فاخترها من القائمة. لا تُحسب أي قيمة من ملف مجهول الأبعاد.
اختر المعالجة
التسوية المستوية تكفي معظم الصور. استعمل كثيرة الحدود من الدرجة الثانية إن ظهر تقوّس الماسح، ومحاذاة الأسطر إن ظهرت خطوط أفقية بين أسطر المسح. المرشحان مغلقان حتى تفتحهما.
حلّل ونزّل
اضغط Analyze، وراجع الرسوم والجدول والتنبيهات، ثم نزّل التقرير بالعربية أو بالإنجليزية، أو الجداول، أو الرسم. ومع عدة ملفات يبدأ التقرير بجدول مقارنة بين العينات.
خيارات المعالجة
| التسوية | طرح مستوى (الدرجة الأولى) أو سطح من الدرجة الثانية بالمربعات الصغرى، لإزالة ميل العينة وتقوّس الماسح. |
|---|---|
| محاذاة الأسطر | طرح وسيط كل سطر مسح بعد التسوية، لإزالة القفزات بين الأسطر. لا تستعملها مع سطح فيه خطوط حقيقية موازية لاتجاه المسح. |
| مرشح L | يزيل التموج الأطول من λc، فتصف المعاملات الخشونة الأقصر منه فقط. |
| مرشح S | يزيل الضجيج الأقصر من λs، ويُختار عادة بضعة أضعاف خطوة البكسل. |
| عتبة الحبيبات | تلقائية بطريقة Otsu، أو نسبة مئوية من مدى الارتفاع تكتبها أنت. |
| مدى ملاءمة الطيف | جزء من تردد نايكويست تُقاس فيه الميل، والافتراضي من 0.02 إلى 0.25. |
كيف تقرأ النتائج
معاملات الارتفاع
بعد التسوية تُقاس الارتفاعات z من مستواها المتوسط، وتُحسب المعاملات على N بكسلًا:
Ssk الموجب يعني قممًا حادة فوق قاعدة مستوية، كالحبيبات، والسالب يعني هضبة تتخللها حفر أو خدوش. وSku = 3 للسطح الغاوسي، وما فوقها يدل على قمم أو حفر قليلة متطرفة. أما Sz = Sp + Sv فيعتمد على نقطتين فقط ويتأثر بالغبار، وS10z يأخذ متوسط خمس قمم وخمسة أودية فهو أثبت.
الميل والمساحة
الميل نسبة بلا وحدة، فيُحوَّل الارتفاع والمسافة إلى الوحدة نفسها قبل الحساب. ويكبر المعاملان كلما صغرت خطوة البكسل، فلا تقارن إلا عينات مسحت بالدقة نفسها.
الحجم الجانبي والاتجاه
تحسب الأداة دالة الارتباط الذاتي للسطح في كل الاتجاهات. Sal أقصر مسافة تهبط عندها الدالة إلى 0.2، وStr نسبة أسرع هبوط إلى أبطئه: قريبة من 1 للسطح المتماثل، وقريبة من الصفر لسطح فيه خطوط صقل أو محزوز.
الطيف والبعد الكسري
كثافة القدرة الطيفية تبيّن مساهمة كل طول موجي في الخشونة، وتكاملها على كل الترددات يساوي Sq². وفي السطح المتشابه ذاتيًا تكون خطًا مستقيمًا على المقياس اللوغاريتمي:
لا معنى لـ H وDf إلا إذا كان الطيف مستقيمًا في مدى الملاءمة و0 < H < 1. وإن خرجت القيمة عن هذا المدى كتبت الأداة H بين قوسين، ولم تحسب Df.
دالة ارتباط الارتفاع
تزداد G(r) مع المسافة ثم تتشبع عند 2Sq². ميلها في المسافات الصغيرة يعطي أس الخشونة α، وطول الارتباط ξ هو المسافة التي تبلغ عندها 2Sq²(1 − 1/e). تعطي α المعلومة نفسها التي يعطيها H، لكنها تنحاز نحو 0.5 في الصور المحدودة، فالقيمة المعتمدة هي H من الطيف.
هذان المعاملان يصفان السطح في لحظة القياس فقط. أما آلية النمو فتحتاج سلسلة عينات بأزمنة ترسيب مختلفة، لقياس تغيّر Sq وξ مع الزمن.
الحبيبات
تُعلَّم المناطق الأعلى من العتبة، وتُفصل الحبيبات المتلاصقة بخوارزمية مستجمعات المياه على خريطة المسافة، ثم يُحسب القطر المكافئ من المساحة:
القطر يُقاس عند ارتفاع العتبة لا عند قاعدة الحبيبة، فالعتبة الأعلى تعطي حبيبات أصغر، ويُكتب ارتفاعها في التقرير. والحبيبات التي يقطعها طرف الصورة تُستبعد من إحصاء الأقطار، وتُحسب نصف حبيبة في الكثافة.
المرشحات
المرشحان من النوع الغاوسي، ونفاذيتهما 50 % عند الطول الموجي القاطع. مرشح S يمرر الأطوال الطويلة بالمعامل:
ومرشح L يطرح هذا الجزء الطويل من السطح. كل مرشح يغيّر المعاملات، فتذكر الأداة الطول القاطع في التقرير، ولا تُقارن عينتان إلا بالمرشح نفسه.
كيف تحققنا من دقة الأداةعينات قيمها معروفة، وبيانات منشورة في مجلات محكّمة
اختبرنا الأداة بثلاث طرق: صور مصنوعة حسابيًا نعرف قيمها الصحيحة سلفًا، وصور قياس حقيقية نشرها باحثون مع نتائجهم في مجلات محكّمة، ومقارنة مع برنامج Gwyddion على الصور نفسها. كل الملفات متاحة للتنزيل في آخر هذا القسم لمن أراد أن يعيد الاختبار بنفسه.
عينات قيمها معروفة
ثماني صور بالصيغ المختلفة التي تقرؤها الأداة، لكل منها قيم صحيحة محسوبة من معادلة السطح الذي صُنعت منه. جاءت نتائج الأداة في الثماني كلها داخل حدود السماح:
| العينة | المعامل | الصحيح | الأداة |
|---|---|---|---|
| محزوز جيبي | Sq | 7.071 nm | 7.05 nm |
| محزوز جيبي | Sal | 0.109 µm | 0.110 µm |
| محزوز جيبي | اتجاه النسيج | 90° | 90.5° |
| سطح كسوري، مصفوفة نصية | H | 0.50 | 0.54 |
| سطح كسوري، ملف XYZ | H | 0.80 | 0.80 |
| حبيبات منفصلة | العدد | 40 | 40 |
| حبيبات متلامسة | العدد | 150 | 150 |
| انحناء ودرجات بين الأسطر | Sq | 2.00 nm | 1.99 nm |
| خشونة فوق تموج، مع مرشح L | Sq | 1.00 nm | 0.96 nm |
وفي العينة ذات الانحناء تعطي التسوية المستوية وحدها Sq = 31.9 nm، أي أكثر من خمسة عشر ضعف القيمة الصحيحة، وهذا ما يبيّن أهمية اختيار التسوية المناسبة. أما الملف الذي لا يحمل طول المسح فترفضه الأداة حتى يُدخل الطول، ثم تعطي القيمة الصحيحة.
بيانات منشورة في مجلات محكّمة
غشاء نتريد النيوبيوم. غشاء رقيق سمكه نحو 6 nm، مرسّب بطبقات ذرية، وقيس بمجهر FRT في الوضع غير التلامسي (Knehr وآخرون، 2021). الصورة بطول 5 µm وبصيغة SDF القياسية.
طلاء ألماس فائق النعومة. أربع وعشرون صورة Bruker في الوضع النقري، بأطوال مسح من 0.1 µm إلى 5 µm (Gujrati وآخرون، 2021).
| المقارنة | المنشور | الأداة | الحكم |
|---|---|---|---|
| النيوبيوم: Sq عند موضع الصورة | 0.818 nm | 0.833 nm | متفق، الفرق 1.8 % |
| النيوبيوم: متوسط الرقاقة | 0.82 nm | 0.833 nm | متفق، الفرق 1.6 % |
| الألماس: H من صورة واحدة | 0.74 ± 0.05 | 0.60 | مختلف |
| الألماس: H من الصور كلها | 0.74 ± 0.05 | 0.50–0.88 | المنشور داخل المدى |
خشونة النيوبيوم تطابق المنشور بفرق أقل من اثنين في المئة، وهو في حدود اختلاف طريقة التسوية بين برنامج الجهاز والأداة. أما أس هيرست للألماس فالقيمة المنشورة محسوبة بطريقة أخرى، وتجمع صور المجهر الإلكتروني النافذ مع صور AFM من عشرة نانومترات إلى عدة ميكرومترات. الصورة الواحدة تغطي جزءًا من هذا المدى، ولذلك اختلفت قيمتها. وعند جمع الصور كلها تتغير القيمة مع مدى الملاءمة بين 0.50 و0.88، والقيمة المنشورة داخل هذا المدى.
مقارنة مع برنامج Gwyddion
شغّلنا العينات الخمس عشرة نفسها في برنامج Gwyddion، وهو برنامج مفتوح المصدر واسع الاستعمال في تحليل صور المجهر (Nečas وKlapetek، 2012). قرأ كل برنامج الملفات بنفسه وحسب المعاملات بدواله، فجاءت قراءة الملفات متطابقة نقطة نقطة، وتطابقت معاملات الارتفاع من Sa إلى Sz ومعها Sdq، واختلف Sdr بأقل من واحد في المئة. وتقارب أس هيرست في البرنامجين، وكانت قيمة الأداة أقرب إلى الصحيح في العينتين اللتين نعرف أسّهما.
نزّل العينات وجرّبها
تنزيل عينات الاختبارالعينات الثماني مع مفتاح الإجابات، والعينات المنشورة مع مراجعهاالعينات المنشورة متاحة برخصة CC BY 4.0، وأصلها في مستودعي Zenodo وcontact.engineering. عند استعمالها اذكر الورقة ومصدر البيانات.
المراجع
- Gujrati, A., Sanner, A., Khanal, S. R., Moldovan, N., Zeng, H., Pastewka, L., & Jacobs, T. D. B. (2021). Comprehensive topography characterization of polycrystalline diamond coatings. Surface Topography: Metrology and Properties, 9(1), 014003. https://doi.org/10.1088/2051-672X/abe71f
- Gujrati, A., Khanal, S. R., Pastewka, L., & Jacobs, T. D. B. (2020). Ultrananocrystalline diamond (UNCD) [Data set]. contact.engineering. https://doi.org/10.57703/ce-8sc7t
- Knehr, E., Ziegler, M., Linzen, S., Ilin, K., Schanz, P., Plentz, J., Diegel, M., Schmidt, H., Il’ichev, E., & Siegel, M. (2021). Wafer-level uniformity of atomic-layer-deposited niobium nitride thin films for quantum devices. Journal of Vacuum Science & Technology A, 39(5), 052401. https://doi.org/10.1116/6.0001126
- Nečas, D., & Klapetek, P. (2012). Gwyddion: An open-source software for SPM data analysis. Central European Journal of Physics, 10(1), 181–188. https://doi.org/10.2478/s11534-011-0096-2
- Knehr, E., Linzen, S., & Ziegler, M. (2022). Measured data of article in J. Vac. Sci. Technol. A 39, 052401 (2021) [Data set]. Zenodo. https://doi.org/10.5281/zenodo.6675357
صيغ الملفات المدعومة
| .gwy | ملف Gwyddion الأصلي. تُقرأ الأبعاد ووحدتا الطول والارتفاع، وتُختار قناة الارتفاع إن تعددت القنوات. |
|---|---|
| .spm .001 | ملفات Bruker وNanoScope. تُقرأ قناة Height Sensor أو Height بالوحدة المخزنة في الملف. |
| .sdf | صيغة بيانات السطح القياسية ISO 25178-71 بنسختيها الثنائية والنصية، وتصدّرها أجهزة كثيرة مثل FRT. تُقرأ منها الأبعاد ووحدة الارتفاع. |
| مصفوفة نصية | صفوف من الارتفاعات، كتصدير ASCII من Gwyddion. تُقرأ الأبعاد ووحدة الارتفاع من الترويسة إن وجدت. |
| XYZ | ثلاثة أعمدة على شبكة منتظمة، بالمتر أو الميكرومتر أو النانومتر، وتُستنتج الخطوة من البيانات. |
وأي صيغة أخرى تصدَّر من برنامج الجهاز أو من Gwyddion إلى إحدى هذه الصيغ.
قبل أن تقارن العينات: امسحها بطول المسح نفسه وعدد البكسلات نفسه، وعالجها بالتسوية والمرشحات نفسها، فالمعاملات المكانية والهجينة والطيفية تتغير مع هذه الإعدادات.
صورة AFM ناتجة عن تداخل شكل السطح مع شكل الرأس، فالحبيبات تبدو أعرض مما هي، والحفر الضيقة تبدو أضحل، خاصة إذا اقترب حجم المعالم من نصف قطر الرأس.
من أدوات الباحثين في معامل الفيزياء.
AFM image analysis with Python
AFM Surface Analyzer · v2.1A tool that reads the height image of an atomic force microscope in its real units, computes the areal roughness parameters of ISO 25178, analyses the surface spectrum and grains, and exports a complete PDF report.
The app runs on 64-bit Windows 10 or 11 and is about 80 MB. Windows SmartScreen may appear on the first run because the app is not digitally signed; choose “More info”, then “Run anyway”. The Colab version needs only a Google account.
The tool accepts Gwyddion, Bruker/NanoScope, SDF, ASCII height matrices and XYZ files, and several samples can be uploaded together for comparison.
What the tool gives you
- Height parametersSa, Sq, Ssk, Sku, Sp, Sv, Sz and S10z: the size, distribution and extremes of the height deviations.
- Spatial parametersSal, the typical lateral size of the features; Str, how similar the surface is in all directions; Std, the direction of a lay if there is one.
- Hybrid parametersSdq, the RMS slope of the surface, and Sdr, the extra true area over the projected area.
- Spectrum and fractal dimensionThe power spectral density PSD, and from it the Hurst exponent H and the fractal dimension Df, with the quality of the fit.
- Correlation functionThe height-height correlation function G(r), and from it the roughness exponent α and the lateral correlation length ξ.
- GrainsCount, density per square micrometre, equivalent diameter and its distribution, and coverage, with touching grains separated.
- PDF reportA report in the lab identity, in English or Arabic: height map and 3-D view, parameter table, plots, every processing step applied, and the warnings.
- Editable filesParameter and grain tables as CSV, and the figure as a 300 dpi PNG.
How to use it
Prepare the notebook
Run the first cell once. It loads the lab typeface and logo for the report.
Upload the files
Run the tool cell and choose one or more files. Under each file the tool prints its size in pixels, the scan size and the height unit as it read them; check them before you continue.
Complete missing units
If a text file has no dimensions, type the scan size in micrometres; if it has no height unit, pick it from the list. No value is computed from a file of unknown size.
Choose the processing
Plane levelling is enough for most images. Use a second-order polynomial when the scanner bow is visible, and row alignment when steps appear between scan lines. Both filters stay off until you switch them on.
Analyse and download
Press Analyze, check the plots, the table and the warnings, then download the report in English or Arabic, the tables or the figure. With several files the report opens with a comparison table of the samples.
Processing options
| Levelling | Least-squares subtraction of a plane (first order) or a second-order surface, to remove sample tilt and scanner bow. |
|---|---|
| Row alignment | Subtracts the median of each scan line after levelling, to remove steps between lines. Do not use it on a surface with real features parallel to the scan direction. |
| L-filter | Removes waviness longer than λc, so the parameters describe only the roughness shorter than it. |
| S-filter | Removes noise shorter than λs; usually a few times the pixel size. |
| Grain threshold | Automatic (Otsu), or a percentage of the height range that you enter. |
| Spectrum fit range | The part of the Nyquist frequency where the slope is measured; the default is 0.02 to 0.25. |
How to read the results
Height parameters
After levelling, the heights z are measured from their mean plane and the parameters are computed over N pixels:
A positive Ssk means sharp peaks on a flat base, such as grains; a negative one means a plateau with pits or scratches. Sku = 3 for a Gaussian surface, and higher values point to a few extreme peaks or pits. Sz = Sp + Sv rests on two points only and is sensitive to dust; S10z averages five peaks and five valleys and is more robust.
Slope and area
The slope is dimensionless, so heights and distances are converted to the same unit before the calculation. Both parameters grow as the pixel size shrinks: compare only samples scanned at the same resolution.
Lateral size and direction
The tool computes the autocorrelation function of the surface in every direction. Sal is the shortest distance at which it falls to 0.2, and Str is the ratio of the fastest to the slowest decay: close to 1 for an isotropic surface, close to zero for a surface with polishing marks or a grating.
Spectrum and fractal dimension
The power spectral density shows how much each wavelength contributes to the roughness, and its integral over all frequencies equals Sq². For a self-affine surface it is a straight line on logarithmic axes:
H and Df are meaningful only when the spectrum is straight in the fit range and 0 < H < 1. Outside this range the tool prints H in parentheses and does not compute Df.
Height-height correlation
G(r) rises with distance and saturates at 2Sq². Its slope at small distances gives the roughness exponent α, and the correlation length ξ is the distance at which it reaches 2Sq²(1 − 1/e). α carries the same information as H but is biased toward 0.5 on finite images, so the reference value is H from the spectrum.
These two parameters describe the surface at the moment of measurement only. The growth mechanism needs a series of samples with different deposition times, to follow how Sq and ξ change with time.
Grains
Regions above the threshold are marked, touching grains are separated with a watershed on the distance map, and the equivalent diameter is computed from the area:
The diameter is measured at the threshold height, not at the base of the grain, so a higher threshold gives smaller grains; the threshold height is written in the report. Grains cut by the image edge are left out of the diameter statistics and counted as half a grain in the density.
Filters
Both filters are Gaussian, with 50 % transmission at the cutoff wavelength. The S-filter passes long wavelengths with the weight:
and the L-filter subtracts this long-wavelength part from the surface. Every filter changes the parameters, so the tool states the cutoff in the report, and two samples are compared only with the same filter.
How we validated the toolSamples with known values, and data published in peer-reviewed journals
We tested the tool in three ways: images computed from surfaces whose correct values are known in advance, real measurements published by researchers together with their results in peer-reviewed journals, and a comparison with Gwyddion on the same images. All files can be downloaded at the end of this section for anyone who wants to repeat the test.
Samples with known values
Eight images in the different formats the tool reads, each with correct values computed from the surface it was made from. The tool’s results for all eight fall within the tolerance:
| Sample | Parameter | True | Tool |
|---|---|---|---|
| Sinusoidal grating | Sq | 7.071 nm | 7.05 nm |
| Sinusoidal grating | Sal | 0.109 µm | 0.110 µm |
| Sinusoidal grating | Lay direction | 90° | 90.5° |
| Self-affine, text matrix | H | 0.50 | 0.54 |
| Self-affine, XYZ file | H | 0.80 | 0.80 |
| Separate grains | Count | 40 | 40 |
| Touching grains | Count | 150 | 150 |
| Bow and line steps | Sq | 2.00 nm | 1.99 nm |
| Roughness on waviness, L-filter | Sq | 1.00 nm | 0.96 nm |
On the bowed sample, plane levelling alone gives Sq = 31.9 nm, more than fifteen times the true value, which shows why the right levelling matters. A file without a scan size is refused until the size is entered, and then gives the correct value.
Data published in peer-reviewed journals
Niobium nitride film. A film about 6 nm thick, grown by atomic layer deposition and measured with an FRT microscope in non-contact mode (Knehr et al., 2021). One 5 µm image in the standard SDF format.
Ultrananocrystalline diamond coating. Twenty-four Bruker images in tapping mode, with scan sizes from 0.1 µm to 5 µm (Gujrati et al., 2021).
| Comparison | Published | Tool | Verdict |
|---|---|---|---|
| NbN: Sq at the image position | 0.818 nm | 0.833 nm | agrees, +1.8 % |
| NbN: wafer mean | 0.82 nm | 0.833 nm | agrees, +1.6 % |
| Diamond: H from one image | 0.74 ± 0.05 | 0.60 | differs |
| Diamond: H from all images | 0.74 ± 0.05 | 0.50–0.88 | published value in range |
The NbN roughness matches the published value within two percent, the size of the difference expected between the levelling of the instrument software and of the tool. For the diamond coating, the published Hurst exponent was computed with another method and combines transmission electron microscopy with AFM from ten nanometres to several micrometres. A single image covers only part of that range, so its value differs. With all images combined, the value changes with the fit band between 0.50 and 0.88, and the published value lies inside this range.
Comparison with Gwyddion
We ran the same fifteen samples in Gwyddion, the widely used open-source program for scanning-probe data (Nečas & Klapetek, 2012). Each program read the files itself and computed the parameters with its own functions. The files were read identically, point by point; the height parameters from Sa to Sz and Sdq agreed exactly, and Sdr within one per cent. The Hurst exponents were close, and the tool’s value was nearer the true one on the two samples whose exponent is known.
Download the samples and try them
Download the test samplesThe eight samples with their answer key, and the published samples with their referencesThe published samples are licensed CC BY 4.0 and come from the Zenodo and contact.engineering repositories. Cite the paper and the data source when you use them.
References
- Gujrati, A., Sanner, A., Khanal, S. R., Moldovan, N., Zeng, H., Pastewka, L., & Jacobs, T. D. B. (2021). Comprehensive topography characterization of polycrystalline diamond coatings. Surface Topography: Metrology and Properties, 9(1), 014003. https://doi.org/10.1088/2051-672X/abe71f
- Gujrati, A., Khanal, S. R., Pastewka, L., & Jacobs, T. D. B. (2020). Ultrananocrystalline diamond (UNCD) [Data set]. contact.engineering. https://doi.org/10.57703/ce-8sc7t
- Knehr, E., Ziegler, M., Linzen, S., Ilin, K., Schanz, P., Plentz, J., Diegel, M., Schmidt, H., Il’ichev, E., & Siegel, M. (2021). Wafer-level uniformity of atomic-layer-deposited niobium nitride thin films for quantum devices. Journal of Vacuum Science & Technology A, 39(5), 052401. https://doi.org/10.1116/6.0001126
- Nečas, D., & Klapetek, P. (2012). Gwyddion: An open-source software for SPM data analysis. Central European Journal of Physics, 10(1), 181–188. https://doi.org/10.2478/s11534-011-0096-2
- Knehr, E., Linzen, S., & Ziegler, M. (2022). Measured data of article in J. Vac. Sci. Technol. A 39, 052401 (2021) [Data set]. Zenodo. https://doi.org/10.5281/zenodo.6675357
Supported file formats
| .gwy | Native Gwyddion file. Dimensions and the lateral and height units are read, and the height channel is chosen when there are several channels. |
|---|---|
| .spm .001 | Bruker and NanoScope files. The Height Sensor or Height channel is read in the unit stored in the file. |
| .sdf | The standard surface data format of ISO 25178-71, binary or text, exported by many instruments such as FRT. Dimensions and the height unit are read from the file. |
| Text matrix | Rows of heights, such as an ASCII export from Gwyddion. Dimensions and height unit are read from the header when present. |
| XYZ | Three columns on a regular grid, in metres, micrometres or nanometres; the step is derived from the data. |
Any other format can be exported to one of these from the instrument software or from Gwyddion.
Before comparing samples: scan them with the same scan size and number of pixels, and process them with the same levelling and filters; the spatial, hybrid and spectral parameters change with these settings.
An AFM image is the surface convolved with the shape of the tip: grains look wider than they are and narrow pits look shallower, especially when the features approach the tip radius.
Part of the research tools of Phy-Lab.
