تجربة تتبع الأشعة في العدسات والمرايا

Ray Tracing with Lenses and Mirrors

تتبّع الأشعة في العدسات والمراياRay Tracing with Lenses and Mirrors

تتبّع خمسة أشعة متوازية خلال عدسة أو على مرآة، وعيّن البعد البؤري من نقطة التقاء الأشعة، ثم قارنه بالقيمة النظرية من أبعاد العدسة أو المرآة؛ وتحقق من قانون الانعكاس في المرآة المستوية.Trace five parallel rays through a lens or onto a mirror, find the focal length from the point where the rays meet, and compare it with the theoretical value from the dimensions of the lens or mirror; and verify the law of reflection with a plane mirror.

الهدف والأجهزةObjective and apparatus

استعمال تتبّع الأشعة لتعيين البعد البؤري للعدسات والمرايا بالرؤية، ودراسة الانعكاس الكلي الداخلي، وتعيين الزاوية الحرجة للزجاج.

To use ray tracing to determine the focal lengths of lenses and mirrors visually; to study total internal reflection; and to determine the critical angle for glass.

  • صندوق ضوئي يعطي خمسة أشعة
  • عدسات (محدبة ومقعرة)، ومرايا (مستوية ومقعرة ومحدبة)، ومنشورات
  • يحضر الطالب: مسطرة صغيرة بالسنتيمتر، ومنقلة، وأقلام رصاص لينة، وورقاً أبيض
  • Light box giving five rays
  • Lenses (convex and concave), mirrors (plane, concave and convex), and prisms
  • Bring: a small ruler with a cm scale, a protractor, soft pencils, and white paper

الأساس النظريTheory

العدسة المحدبة: الأشعة المتوازية تلتقي بعد العدسة في نقطة واحدة F هي البؤرة، والمسافة بين F والعدسة هي البعد البؤري f. وقيمته النظرية من أبعاد العدسة:

Convex lens: parallel rays meet after the lens at one point F, the focus, and the distance between F and the lens is the focal length f. Its theoretical value from the dimensions of the lens is:

$$f=\frac{a^{2}}{2b\,(n-1)},\qquad b=t_{\text{center}}-t_{\text{edge}}$$
(1)

حيث a نصف قطر العدسة (نصف ارتفاعها 2a)، وb «الانتفاخ»: سمك المركز ناقص سمك الحافة (موجب للمحدبة)، وn معامل انكسار البلاستيك (عادة 1.5)، والأطوال كلها بالسنتيمتر.

where a is the radius of the lens (half its height 2a), b the bulge: centre thickness minus edge thickness (positive for a convex lens), and n the refractive index of the plastic (typically 1.5), all lengths in centimetres.

العدسة المقعرة: تُتتبّع الأشعة بالطريقة نفسها، لكنها تتفرق بعد العدسة، فتُمدّ إلى الخلف بخطوط متقطعة حتى تلتقي في البؤرة F قبل العدسة. هنا f < 0، وb < 0 في المعادلة (1).

Concave lens: the rays are traced the same way, but they diverge after the lens, so they are extended backwards with dashed lines until they meet at the focus F before the lens. Here f < 0, and b < 0 in equation (1).

المرآة المستوية: ارسم العمود على المرآة عند نقطة السقوط، وقِس بالمنقلة زاويتي السقوط والانعكاس عن العمود:

Plane mirror: draw the normal to the mirror at the point of incidence, and measure with the protractor the angles of incidence and reflection from the normal:

$$\theta_{\text{in}}=\theta_{\text{out}}$$
(2)

المرآة المقعرة: الأشعة المنعكسة تلتقي في البؤرة F أمام المرآة، والبعد البؤري هو المسافة من F إلى المرآة. وقيمته النظرية نصف نصف قطر التقوس R، الذي يُعيّن من رسم المرآة على الورق بإحدى طريقتين: من وتر القوس 2a وعمقه b، أو برسم أعمدة على القوس تلتقي في مركزه فتكون R المسافة من المركز إلى المرآة:

Concave mirror: the reflected rays meet at the focus F in front of the mirror, and the focal length is the distance from F to the mirror. Its theoretical value is half the radius of curvature R, found from the trace of the mirror on paper by either method: from the chord of the arc 2a and its depth b, or by drawing normals to the arc that meet at its centre, so that R is the distance from the centre to the mirror:

$$f=\frac{R}{2},\qquad R=\frac{a^{2}}{2b}$$
(3)

المرآة المحدبة: الأشعة المنعكسة تتفرق، فتُمدّ خلف المرآة لتلتقي في البؤرة F، والبعد البؤري سالب: f = −R/2.

Convex mirror: the reflected rays diverge, so they are extended behind the mirror to meet at the focus F, and the focal length is negative: f = −R/2.

المنشور والانعكاس الكلي الداخلي (هذا الجزء غير مفصّل في ملف التجربة، وأُضيف لتحقيق هدفها الثاني والثالث): نستعمل منشوراً نصف دائري، فيدخل الشعاع وجهه المنحني باتجاه المركز دون أن ينحرف، ثم يسقط على الوجه المستوي من الداخل بزاوية θ، ويخرج إلى الهواء بزاوية φ أكبر منها حسب قانون سنل. وبزيادة θ تصل φ إلى 90°، وعندها تكون θ هي الزاوية الحرجة θc، وبعدها ينعكس الضوء كله داخل المنشور:

The prism and total internal reflection (this part is not detailed in the experiment sheet; it is added to meet its second and third objectives): we use a semicircular prism, so the ray enters its curved face towards the centre without bending, then meets the flat face from inside at an angle θ, and leaves into air at a larger angle φ by Snell’s law. As θ increases, φ reaches 90°; θ is then the critical angle θc, and beyond it all the light is reflected inside the prism:

$$n\sin\theta=\sin\varphi\;\Rightarrow\;n=\frac{\sin\varphi}{\sin\theta},\qquad \sin\theta_c=\frac{1}{n}$$
(4)

المعادلتان (1) و(3) تقريبيتان للانتفاخ الصغير: الدقيقة لنصف قطر القوس R = (a² + b²)/(2b)، والأشعة البعيدة عن المحور تلتقي أقرب قليلاً (الزيغ الكروي).

Equations (1) and (3) are approximations for a small bulge: the exact radius of the arc is R = (a² + b²)/(2b), and rays far from the axis meet slightly closer (spherical aberration).

خطوات التجربةProcedure

  1. ضع الصندوق الضوئي والعدسة المحدبة على ورقة فوق الطاولة، وأطفئ أنوار الغرفة حتى ترى الأشعة خطوطاً مضيئة على الورق. استعمل خمسة أشعة، وتأكد أن الشعاع الأوسط يمر بمركز العدسة.
  2. ارسم حدود الصندوق والعدسة على الورق، وضع لكل شعاع نقطتين متباعدتين قبل العدسة وبعدها.
  3. ارفع الصندوق والعدسة، وصِل كل نقطتين بخط مستقيم بالمسطرة؛ هذا «تتبّع الأشعة»، ويُسلَّم ضمن أوراق البيانات.
  4. عيّن نقطة التقاء الأشعة F، وقِس البعد البؤري f وسجّله، وقِس a وسمكي المركز والحافة، وقارن بالقيمة النظرية (1).
  5. كرّر مع العدسة المقعرة، ومُدّ الأشعة المتفرقة إلى الخلف بخطوط متقطعة.
  6. المرايا: ارسم الأشعة المنعكسة بخطوط متقطعة. في المرآة المستوية ارسم العمود، وقِس θin وθout لعدة أشعة.
  7. المرآة المقعرة: اجعل الشعاع الأوسط يسقط على منتصف المرآة، وقِس f من F إلى المرآة، وارسم المرآة على الورق لتعيين R، وقارن بـ R/2.
  8. المرآة المحدبة: مُدّ الأشعة المنعكسة خلف المرآة حتى تلتقي في F، والبعد البؤري سالب.
  9. المنشور (إضافة): ضع المنشور نصف الدائري بحيث يتجه الشعاع الواحد إلى مركز وجهه المستوي، وارسم العمود عند المركز. قِس θ داخل المنشور وφ في الهواء لعدة زوايا.
  10. أدر المنشور ببطء حتى يختفي الشعاع الخارج ويصير الانعكاس كلياً، وقِس هذه الزاوية θc، ثم احسب n بالطريقتين وقارن.
  1. Place the light box and the convex lens on a sheet of paper on the table, and turn down the room lights so that the rays show as bright lines on the paper. Use five rays, and make sure the centre ray passes through the centre of the lens.
  2. Draw the outlines of the light box and the lens on the paper, and for each ray place a pair of dots some distance apart, before and after the lens.
  3. Remove the light box and the lens, and connect each pair of dots with a straight line using the ruler; this is your ray tracing, submitted as one of your data sheets.
  4. Locate the point F where the rays meet, measure and record the focal length f, measure a and the centre and edge thicknesses, and compare with the theoretical value (1).
  5. Repeat with the concave lens, extending the diverging rays backwards with dashed lines.
  6. Mirrors: draw the reflected rays as dashed lines. For the plane mirror draw the normal, and measure θin and θout for several rays.
  7. Concave mirror: make the centre ray hit the middle of the mirror, measure f from F to the mirror, trace the mirror on paper to find R, and compare with R/2.
  8. Convex mirror: extend the reflected rays behind the mirror until they meet at F; the focal length is negative.
  9. Prism (added): place the semicircular prism so that a single ray points at the centre of its flat face, and draw the normal at the centre. Measure θ inside the prism and φ in air for several angles.
  10. Turn the prism slowly until the outgoing ray vanishes and the reflection becomes total, measure that angle θc, then compute n both ways and compare.

لا تنظر مباشرة إلى فتحة الصندوق الضوئي، فمصباحه ساخن. ضع العدسات والمرايا على حوافها بلطف، ولا تلمس أسطحها بأصابعك.

Do not look straight into the light-box slit; its lamp is hot. Stand lenses and mirrors on their edges gently, and do not touch their surfaces with your fingers.

المحاكاة التفاعليةInteractive simulation

اختر العنصر البصري، ثم حرّك الخط الأخضر حتى يقع على نقطة التقاء الأشعة (أصغر انتشار)، وسجّل البعد البؤري. في المرآة المستوية غيّر ميل المرآة وسجّل زاويتي السقوط والانعكاس، وفي المنشور غيّر زاوية السقوط وسجّل الزاويتين، أو سجّل الزاوية الحرجة حين يختفي الشعاع الخارج. الأشعة تُحسب بقانون سنل وقانون الانعكاس على السطوح الكروية الحقيقية.

Choose the optical element, then move the green line onto the point where the rays meet (smallest spread), and record the focal length. For the plane mirror, change the mirror tilt and record the angles of incidence and reflection; for the prism, change the angle of incidence and record both angles, or record the critical angle when the outgoing ray vanishes. The rays are computed with Snell’s law and the law of reflection on the real spherical surfaces.

عناصر المحاكاة: عدسات بلاستيكية n = 1.50، ومرايا كروية. المسطرة بالسنتيمتر ومركزها العنصر البصري. المحاكاة نموذج لا قياس.Simulation elements: plastic lenses with n = 1.50, and spherical mirrors. The scale is in centimetres with the optical element at its centre. The simulation is a model, not a measurement.

إدخال البياناتData entry

سالب للعدسة المقعرة والمرآة المحدبةnegative for the concave lens and the convex mirror
