Used in conjunction with sensors from the CASSY family, Mobile-CASSY can perform varied measurements in the fields of physics, chemistry, and biology, e.g. measurement of temperature, conductivity, pH value, pressure, force, heart rate and many other quantities.
Up to four measured values can be displayed at the device, which offers several type sizes to be selected from.
If Mobile-CASSY is used in conjunction with CASSY Lab (524 220), the computer can be employed
for large-screen displays and for recording measured values.
With integrated real-time clock and data logger.
Data memory for up to 16,000 measured values is preserved after switching off and can thus be read by
CASSY Lab via the USB port later on
The performance can be expanded by updating via CASSY Lab at any time.
Simplified charging by built-in rechargeable battery.
Technical Data
Scanning rate: max. 5 values/s
Number of measurement quantities: max. 8 (depending on sensor) per Mobile CASSY
Measurement quantities and ranges are changed automatically after connected a sensor box (automatic recognition of sensor box).
For more details regarding the available measurement ranges see at the sensors.
Data logger: max. 16.000 measured values
Scanning interval: adjustable from 5 values/s to 1 value/h
Connections
USB (compatible with 1.x and 2.0, isolated)
Cannon plug for plug-in power supply 12 V AC/DC
CASSY sensor connector site (15-pole)
Built-in rechargeable battery
Capacity: 9 Wh
Dimensions: 87 mm x 215 mm x 30 mm
Optical Power Sensor S
Sensor: Si (7 mm2)
Connections: FSMA, unassembled PMMA fibres (2.2 mm) via supplied adapter
Wavelengths: 665 nm, 820 nm
Absolute measuring range:-5 … -55 dBm
Relative measuring range: +50 … -50 dB
Resolution: 0.1 dB
Absolute exactness: 1 dB
Dimensions: 50 mm x 25 mm x 60 mm
Weight: 0.1 k Weight: 350 g
Lux adapter S
